D50P1DS Nidec | 50 Hp 3600 RPM 324TS Frame 208-230/460V ODP Electric Motor Nide

• 50 hp 3600 RPM, 117.0/59.0 amps 208-230/460V, 50/60hz. Three Phase
• NEMA 324TS Frame Keyed Shaft 1 7/8″ Diameter x 3 3/4″
• ODP; Service Factor: 1.15, Overload protection = None
• Reversible, Rigid Base Mount, Ball Bearings, Class F Insulation
• “C” Dimension 25.8″
• 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase electric motor. Continuous Duty.  Premium efficient. 40C Ambient Temp. Wiring diagram on motor name plate. ODP = Open Drip Proof

Model DC33
